Home > Application > Hotels Industry

Hotels Industry

Central Heating and hot water boilers are used in hotel, university, bath center, greenhouse, etc. for heating and hot water supply. Yongxing Group supplies steam boiler and hot water to meet client's heating and hot water needs.

Hotels Industry

Type:  Hot Water Boiler for heating and domestic water, Steam Boiler for Heating

Heating Condition: it's proved that 1 ton boiler can heat  almost 10,000 square meter area. (The heating boiler should be at least 0.5ton )

Heating Field: Hotel, Hospital, Building Office, Greenhouse Central Heating, Supermarket, Industrial Workshop, School, University, Bath Center, etc.

Heat Source for Heating Boiler: Natural Gas, Biogas, Diesel Oil, Heavy Oil, LPG, Biomass, Coal, Co-fiirng, Dual Fuel, Multi-fuel, etc.

Hotels Industry


Types and Specifications of Boilers Suitable for Hotels Industry
CWNS Single Drum Hot Water Boiler
CWNS Single Drum Hot Water Boiler

Capacity: 0.35mw/h - 14mw/h

Pressure: 0 Mpa

Fuel: Natural gas, lpg, Light Oil, Diesel, Heavy oil,dual fuels.

The CWNS gas/oil fired hot water boiler can be used for producing desired hot water for hotels, schools, hospital, product manufacturing process in the weave factory,printing and dying, papermaking, and rubber, plastic chemical, pharmaceutical, etc. And for heating room, bath, air conditional, and daily life water in the factories, departments, hotels, schools, restaurants, services industries etc.

DZL Single Drum Automatically Boiler
DZL Single Drum Automatically Boiler

Capacity:0.5t/h-20t/h  0.35mw/h - 14mw/h

Pressure:0.7Mpa-2.5Mpa

Fuel:Coal, Biomass pellet, Rice Husk, Bagasse, etc.

DZL type boiler is horizontal three return water fire tube boiler. In the left and right sides of the furnace is arranged into rows of water wall tube, inside the drum are arranged two bundles constitute two return. This type of boiler adequate heating surface and are equipped with plate and tail heating surface economizer in.

CSZS Double Drums Hot Water Boiler
CSZS Double Drums Hot Water Boiler

Capacity: 4.2mw/h - 14mw/h

Pressure: 0 Mpa

Fuel: Natural gas, lpg, Light Oil, Diesel, Heavy oil,dual fuels.

CSZS series hot water boiler body is double-drum, horizontal with D-type combustion chamber, the furnace is on the right, and the convection tubes on the left, movable supports in the midst and both sides of the furnace are mixed into the bottom plate of the boiler body, making sure that the boiler is expanding toward both sides in the whole.

How to Select a Proper Boiler for hotels industry

1. Determine the capacity of the boiler. The boiler capacity should based on the Heating Load Curve or Heat Balance Diagram, and includes the heat loss in pipelines, self-used heat of boiler room, available used waste heat. While, usually, it is difficult to get the Heating Load Curve, the heating load could get based on the max thermal consumption per hour within production/heating/domestic, and then determine by using the coefficient.

2. Determine the boiler heating parameters, including pressure, temperature, etc.

3. Determine the boiler efficiency. In order to benefit for economic management, the boilers should have high thermal efficiency, and the boiler output, quantity and other performances have to adapt to the change of heat loading.

4. It is better to select the boilers with same capacity or combustion equipment. If different, the max limitation is two models, to decrease the problems of equipment layout and management.
